The Photonic Desk-set is composed of the LED Hi-Power Spot (2 pieces), 2 spot holders (flexible arms) and 2 base plates. The Hi-Power Spot must be attached to the included Spot holder. This Spot holder is then mounted onto the round Base plate. With this set you can create two individual Hi-power spots with flexible arms. As it is mounted on the baseplate, it can be placed anywhere around the sample creating total flexibility. The brightness can be controlled by the compact control unit. Furthermore you can switch on/off the 2-arms individually.

The Photonic HPS-set is composed of the LED Hi-Power Spot 2-arm and the RK-06A/RK-06AE/RK-06F adapters.

This spot is used for direct attachment to microscope stands, like the Dino-Lite RK-06A/RK-06AE/RK-06F stands. As it is mounted on the stand, it is perfect for use in small spaces. The brightness can be controlled by the compact control unit. Furthermore you can switch on/off the 2-arms individually. The flexible arms can be easily adjusted to provide the best angle of illumination to your sample.

Equipped with an adjustable and also a removable polarizer, BL-ZW2 backlight offers parallel to cross-polarization and can transmit plain light by removing the polarizer. BL-ZW2 is designed to image birefringent properties for distinguishing anisotropic from isotropic materials, detecting defects, or examining internal stresses, making it suitable for industry, petrography, and biology applications.

The MS08B is an ultra-portable mini stand that holds the Dino-Lite in place whenever you need to. The MS08B is a great little accessory to enhance the Dino-Lite's microscopic portability solution.

From metal; 7.5cm (W) x 10cm (L) x 14,5cm (H), weight 500g

The Dino-Lite AM4517MZT is part of the EDGE PLUS series, a special category within the Universal range. It offers a magnification range of 10-220x with 1.3MP and a USB 2.0 connection at 30fps. It offers superb image quality and clarity and color reproduction in a robust, compact and appealing metal housing.

The AMR function automatically detects and displays the magnification of the Dino-Lite. The magnification is displayed within the Dino-Lite software and stored with the captured picture and simplifies the measuring process. Because of the built-in polarization filter this model is ideal when working with shiny or reflective objects such as metal, plastic, glass, jewelry, electronics, etc.

The AF3113T has both the measurement functions and the Microtouch button to capture pictures directly from the Dino-Lite. The improved image sensor provides a high quality image with very natural colors and it also offers a high refresh rate for better real time images. It is an affordable solution for industrial, scientific and business use.

Short Description 640x480 Resolution 8 white LEDs (switchable) 10-70, 200x magnification Measurement functionality Wireless ready

The AM3111 digital microscope is an economical pick that provides smooth imaging and balanced color performance, making it suitable for a variety of applications, such as simple industrial inspections, educational use, or personal hobbies.

Smooth Imaging: The CMOS image sensor transmits smooth images at up to 60 fps with 640 x 480 resolution.
Adjustable Magnification: The adjustable magnification ranges from 20x ~ 50x for a broad view to over 200x for detailed close-ups, easily controlled with the focus knob.

The AM4113TL-M40 is a special version of the long working distance series with a lower magnification rate of between 5 and 40 times.

Short Description 1.3 Megapixel resolution With magnification lock 5-40x magnification Long working distance Great choice for generic applications

The Dino-Lite RK-06A stand is a sturdy and stable mid-range stand solution that can be used with all Dino-Lite digital microscopes. It is constructed of stainless steel and lightweight aluminum and offers precise fine-focus adjustment as well as a quick vertical release function.

Its adjustable horizontal arm has a 15cm range with 360-degree rotation and with the RK-10-EX arm (included) its effective range can be extended to observe larger objects. Various optional accessories are available for the RK-06A, such as the RK-10-FX flexible arm or the RK-10-PX, XY arm. With these features, the RK-06A is the ideal mid-range stand solution for precise orientation and maximum flexibility.

The Dino-Lite RK-04 stand has a robust, lightweight and compact rack design. It is designed with portability and convenience in mind. All Dino-Lite microscopes are compatible with this stand with the exception of the Long Working Distance microscopes.

The Dino-Lite RK-04F stand has a robust, lightweight and compact rack design. Additionally it has an integrated fine focus adjustment knob to make focusing easier and more precise. The RK-04F is the perfect accessory for users requiring flexibility. All Dino-Lite microscopes are compatible with this stand with the exception of the Long Working Distance microscopes.

The LED light source F1 was specially designed to be used in very challenging conditions of industrial environments. This illumination solution combines vibration-free and silent operation with absolute reliability over the LED life span of 50.000 hours.

The compatibility of the F1 with PHOTONIC light guides and via customer-specific adapters with other light guides make it one of the most versatile industrial light sources on the market.

The compact design, a unique cooling concept and her absolute reliability in rough conditions convince our customers. In combination with the extensive accessories a broad variety of illumination forms can be realized, which are crucial in quality assurance to deliver outstanding products.

Type: light source
Illumination Technology: LED
Power supply: external power supply
Voltage: 100 – 240 VAC
Max. light guide diameter: light guide connector Ø 15 mm, galvanically separated, active diameter: max. 9 mm
Light guide type: standard light guide
Filter: no
Features: absolutely vibration-free and silent, minimal energy consumption

The SL-ZW1 is a polarized USB powered gooseneck light with the ability for the polarization to be adjusted by a simple rotation on the accessory itself. To take advantage of the polarizing light, the accessory is ideally suited to work with Dino-Lite models that have the polarization filter.

The AM8917MT4A is a feature-packed microscope integrated with coaxial light and EDOF, answering needs for inspecting reflective surfaces and capturing all-in-focus images under 400x magnification. AM8917MT4A includes advanced features such as DPQ, EDR, AMR, and both Auto and Manual Refocusing.

With the use of the latest, cutting-edge optics, a brand new 5 megapixel sensor and several special features such as flexible LED control (FLC), Automatic Magnification Reading (AMR) and full aluminum body, the Dino-Lite AF7515MZT is a marvel of technology and the best choice for the high-demanding professional. The Dino-Lite AF7515MZT offers superb image quality and color reproduction in a robust, compact and appealing housing.

The AF7515MZT is part of the universal range and with its standard working distance and wide magnification range from 10 – 220x, it is suitable for a wide range of applications. Because of the built-in polarization filter this model is ideal when working with shiny or reflective objects such as metal, plastic, glass, jewelry, electronics, etc. The AMR function is of particular importance when the measurement functions are frequently used.

Taking image quality to the next level, the 8-megapixel AM8117MZT digital microscope delivers high resolution and color fidelity for a natural-looking and detailed imaging experience. AM8117MZT includes a polarizer for reducing unwanted reflections as well as eFLC for maximizing lighting adjustability.

Short Description High Optical Resolution 8.0 Megapixel Enhanced Flexible LED Control (eFLC) Adjustable Polarizer Robust Metal Housing

The AM4113TL is a special model with long working distance up to 15 cm at 20x magnification and around 4cm at 90x magnification. The extra working distance makes the TL series an ideal solution for tasks where you need more working distance to the object, for example repair, rework or assembly tasks.

Short Description 1.3 Megapixel resolution With magnification lock 10x ~ 90x magnification Long working distance

The Dino-Lite AF4135ZTLE is part of Long Working Distance (LWD) series and connects to your device via USB. The AF4135ZTLE is Wireless-ready, but requires the (optional) WF-20 to make it a fully wireless solution.

In comparison, the AF4x35 series provides a similar working distance range but achieves higher magnifications compared to the AM4x15 series.

Short Description 1.3 Megapixel Edge sensor 10x~200x magnification Flexible LED Control (FLC) Polarizer Wireless-ready

The Dino-Lite Edge models provide superior image quality and a high level of flexibility due to the adaptable cap design. The built-in adjustable polarizer reduces glare and reflection on shiny objects. With the Extended Dynamic Range (EDR) feature, the details of darker or brighter areas within the object can be revealed by stacking images at different exposure levels. The Extended Depth of Field (EDOF) feature automatically stacks images at different focus level to improve the depth of field on rough or uneven surfaces. Different caps are supplied with the microscope making the Dino-Lite Edge the perfect choice for any professional application.

Short Description 1.3 Megapixel EDGE sensor Versatility due to exchangeable caps 20-220x magnification Polarizer (anti-reflection) Ext. Dynamic Range (EDR) Ext. Depth of Field (EDOF)

The AM4113ZT4 with a high magnification of 430x ~ 470x reveals even the smallest details on all kinds of objects. The built-in, switchable polarizer makes the AM4113ZT4 the right choice for working with high glare materials such as jewelry, plastics and metals.

Short Description 1.3 Megapixel resolution With magnification lock 430x ~ 470x magnification Polarizer (anti-reflection)

The AM4113T5 with a high magnification of 500x reveals even the smallest details on all kinds of objects. This model also provides the possibility to calibrate the microscope for measurements.

Short Description 1.3 Megapixel resolution With magnification lock 500x Magnification For high magnification applications

The Dino-Lite WF4115ZT is a Wireless model that is part of the Universal series. Go from wireless to wired and back in an instant. Work wired via USB or work wireless with the attachable WF-20 Wireless adapter.

Short Description 1.3 Megapixel Edge sensor 20-220x magnification Adjustable polarizer Flexible LED Control (FLC) Free iOS and Android App

The Dino-Lite WF4515ZT is a Wireless model that is part of the Universal series. Go from wireless to wired and back in an instant. Work wired via USB or work wireless with the attachable WF-20 Wireless adapter.

Short Description 1.3 Megapixel Edge sensor 20-220x magnification Adjustable polarizer Flexible LED Control (FLC) Automatic Magnification Reading (AMR)

The Dino-Lite WF4915ZT is a Wireless model that is part of the Universal series. Go from wireless to wired and back in an instant. Work wired via USB or work wireless with the attachable WF-20 Wireless adapter.

Short Description 1.3 Megapixel Edge sensor Extended Depth of Field (EDOF) Extended Dynamic Range (EDR) Flexible LED Control (FLC) Automatic Magnification Reading (AMR)
