Measuring instruments
For measuring the strength of pure alcohol. Built-in thermometer with compensation scale. In plastic case. 0-100 Vol %, length 320 mm, 40 g
Temperature, air pressure and humidity | |
Diameter | 70/70 mm |
Material | Solid oak |
Assembling | Wall mounting |
Dimensions | (L) 92 x (B) 38 x (H) 170 mm |
Weight | 182 g |
With hanging loop, d=100mm
- Outside temperature and humidity via transmitter
- Room climate with indoor temperature and humidity
- Weather forecast with symbols, air pressure history
- Programmable alarm conditions, storm warning
- Radio clock with alarm and date, backlit display
For monitoring X-rays, beta and gamma rays, with alarm to protect people from radiation;
TFT color screen for easy operation, acoustic and visual alarms, alarm thresholds can be set;
Measures dose rates in real time and records total doses
Calibration function
Adjustable alarm thresholds
Display of the current total dose
Time-controlled measurement: 0 - 999 h
Alarm when limit values are exceeded
Saves the recordings of the last 10 measurements
Display of the battery status
Warning in case of sensor errors
Included in delivery:
Carrying case, data cable, wrist strap and manual
Display: TFT 2.0 color screen
Sensor: G-M counter
Detected rays: X-ray, beta and gamma
Range: 0.05 µSv ... 50 mSv
Accuracy: -17% ... + 25%
Alarm response time: <10 sec.
Alarm modes: acoustic and visual alarm
Battery: 3.7 V / 1800 mAh
Battery life: 20 days (continuous measurement, sound off)
Weight: 127 g
Dimensions: 120 x 65 x 25 mm
Versatile, easy to use and compact precision instrument for measuring α-, β- and γ-radiation. With filter selection switch at the front of the Geiger-Müller counter tube for filtering out types of radiation (γ/β, γ/α/β or γ only), large display and integrated USB interface. Includes USB cable and operating instructions. The necessary software can be downloaded from the manufacturer's website.
The following functions and operating modes are available for measurement:
- Standard mode for displaying the current radiation level. Display of the equivalent dose as a numerical value and as a bar chart and display of the time until a selected cumulative dose limit is reached (default 5 μSv/h). Also equipped with variable acoustic and optical warning threshold signal and display of average radiation from previous day.
- Pulse counting either permanent or with variable gate time. Gate time adjustable in seconds, minute or hours. Additional optional acoustic count indication.
- Count rate measurement. The pulses registered are measured successively and converted into a count rate (number of pulses per second).
- Integrated display of date and time for correct recording of measured radiation.
- The number of pulses registered is stored in the internal memory. This facilitates recording e.g. of weekly values for up to 10 years.
- Computer docking station. The software enables the measured data to be evaluated and processed on an MS-Windows PC.
Specifications:
- Radiation types: α from 4 MeV, β from 0.2 MeV, γ from 0.02 MeV
- Measured variables: equivalent dose in Sv/h, mSv/h, μSv/h, pulses/s, pulses/variable time interval
- Display: LCD, 4 digit, numerical with display of measured variable, quasi analogue bar chart, operating mode indicators
- Radiation detector: End window Geiger-Müller counter tube, stainless steel housing with neon-halogen filling
- Measuring length: 38.1 mm
- Measuring diameter: 9.1 mm
- Mica window: 1.5 – 2 mg/cm²
- Gamma sensitivity: 114 pulses/min for 60Co radiation = 1 μSv/h in background radiation energy band
- Background rate: 10 pulses per minute approx.
- Internal memory: 2 kilobytes
- Battery life: 3 years approx.
- Dimensions: 163x72x30 mm³ approx.
- Weight: 155 g approx.
Ideal for the simple measurement of noise levels in your environment, at work or during different leisure activities, equivalent A-weighted sound level (dBA), MAX/MIN/HOLD function, precision ±1,4 dB, backlight, with windshield and tripod screw, according to IEC 61672-1 class 2
Range: dB: 30...130 measures 52 x 35 x 155 mm, kaal 115 g, battery 1x 9V
The UV-resistant weather station contains a rotating weathercock, a rain gauge and an instrument panel with max. min- thermometer, barometer and hygrometer.
With the mounting hole in the base plate and the weather station stand, you can set up these weather station outdoors.
Packed in a cardboard box
Colour-illuminated display with clear layout
Combined transmitter for wind, temperature and humidity
Animated graphic of wind force with wind turbine
Weather forecast with symbols and atmospheric pressure trend
Alarm limits, max. / min. values, dew point
- Combined wireless transmitter for outdoor temperature, humidity and wind speed
- Indoor temperature and humidity
- Weather forecast with symbols and atmospheric pressure trend
- Max.- min.-function, trend indicators, dew point, windchill factor
- Wind speed graph, maximum speed and history (last hour, 24 hours, 7 days, 30 days and year)
- Programmable alarm functions
- Radio-controlled clock with date and day of the week (6 languages)
- Colour display with two brightness levels (continuous operation by power adapter)
- Expandable with 2 thermo-hygro-transmitters (T/H 30.3221.02, sold separately)
