Tools for practical work - upper secondary school

Tools for conducting practical work in upper secondary school physics sections:

kinematics, dynamics, electromagnetism, energy, and the micro and macro world.

25-g Accelerometer
ACC-BTA

Specifications

  • Power: 30 mA @ 5 VDC
  • Range: ±245 m/s² (±25g)
  • Accuracy: ±2.45 m/s² (±0.25g)
  • Frequency Response: 0–100 Hz
  • Typical Resolution: 0.16 m/s²
3-Axis Magnetic Field Sensor
GDX-3MG

The Go Direct 3-Axis Magnetic Field Sensor measures the components of the magnetic field along three orthogonal axes. This allows you to determine the magnitude and direction of the magnetic field at any point in space. If desired, measure the field along only two axes, or even one axis, choosing the direction that is best for the experiment.

The Go Direct 3-Axis Magnetic Field Sensor can be used in a variety of experiments:

  • Quantify the magnetic field strength of induced magnets.
  • Determine the declination and inclination of the Earth’s magnetic field at your location using vector components.
  • Investigate the relationship between magnetic field strength, coils per unit length, and current in the center of a solenoid.

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

Acceleration sensor with altimeter, wireless
GDX-ACC

This 3-axis acceleration sensor has two acceleration ranges plus an altimeter and a 3-axis gyroscope. An additional channel measures the angle of the sensor’s long axis.

  • Measure helmet impacts in concussion-related investigations.
  • Slip it into your pocket and pirouette or ride a half-pipe.
  • Mount this accelerometer on your bicycle or affix it to your lab cart without any dragging cables.

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

Ammeter, DC and AC, analog
1172038

Direct current: 1 / 10 / 100 / 100 mA / 1 A / 10 A, accuracy 2% of full scale

Alternating current: 10 / 100 mA / 1 A / 10 A, accuracy 3% of full scale

DC voltage drop: 250 mV in all ranges

AC voltage drop: 5V (10 mA), 500 mV (100 mA), 50 mV (1 A / 10 A)

Display: moving coil instrument with mirror scale

Analog multimeter
54870

Analogue multimeter with mirror scale, tip-mounted moving coil measuring mechanism and central measuring range rotary switch.

For measuring current, voltage and resistance

20 measuring ranges

Continuity test with acoustic signal

Includes accessories: case, test leads, batteries and operating instructions.

Voltage DC: 3/15/60/150/600 V; ±3.0%

Voltage AC: 15/60/150/600 V; ±4.0%

Current DC: 100 µA/10 mA/500 mA/10 A; ±3.0%

Current AC: 10 mA/500 mA/10 A; ±4.0%

Resistance: 200 Ohm/2/20/200 kOhm/2 MOhm; ±5.0%

Power supply: 3 x 1.5 V AAA batteries

Display: 75 mm mirror scale

Safety: EN 61010-1; CAT II 600 V

Dimensions: 110 x 175 x 45 mm

Weight: 315 g

Bar magnet 150x20x6mm, AlNiCo
22-532
Bar magnet 74x11x6mm, AlNiCo
19-018

Small, strong I-magnet made of AlNiCo material.

Battery 1,5V AA
24-351
Battery 1,5V AAA
24-351a
Battery 4,5V, 3R12
24-086
Battery 9V
24-352
9Vpatarei.jpg6LR61
Beaker 250ml
664130
Beaker 400ml
664131
1PC-font-b-400mL-b-font-Chemistry-Laboratory-font-b-Beaker-b-font-Borosilicate-Glass-font.jpg
Bulb and motor model, DC
27-027

Motor operating voltage 1...6V, bulb operating voltage 6V. Sockets for 4mm connectors.

Cables with magnetic tips, 10 pcs
314350427

Connecting wires with magnetic tips make it easy to build a circuit. The batteries and bulb socket shown in the picture are not included. The set consists of 10 connecting wires.

Calorimeter 200ml, aluminium
22-197

200ml, heating 6V, heating element resistance 2...3 ohms. Aluminum shell d100mm x h100mm, aluminum container 70xd60mm inside. Insulated with polystyrene foam, heating elements with two 4mm pin sockets.

Combination 1.2 m Track/Optics Bench
TRACK

The Combination Dynamics Track and Optical Bench is aluminum and includes a metric scale. Extremely rigid, this 1.2 meter track will not sag under use. The track includes 2 Adjustable Two Foot Levelers.

Composite nylon cord 60m
P71001A

Material: composite nylon

60 linear meters of cord, on a roll with side clamping grooves

Dimensions of the roll: D=22 mm, L=43 mm

Weight: approx. 7 g

Connecting cable 50 cm
22-030

Length 50 cm. Available in different colors, wires are with extendable 4mm banana connectors.

Connection cable 25 cm, 4mm banana plugs
22-038

Length 25 cm. Available in different colors, wires are with extendable 4mm connectors.

Connection cable, 25 cm, with forks
22-579
Connection cable, 25cm, fork - 4mm plug
22-578
Constantan wire 0,2mm/100m
55040
Constantan wire 0,2mm/30m
P33161C

To investigate the dependence of electrical resistance on material, length, cross-section and temperature, to determine the specific resistance;

Resistance wire wound on a coil body

Material: NiCr

Diameter: 0.2 mm

Wire length: 30 m

Mass: approx. 9 g

Copper wire, 0,4 mm, 100m
50806
Cord colored, D1.7 mm, L5 m
DG2001S
Cupper plate 86x26x0,9mm
51753
Cupper wire 0,3mm, 100m
1000949

Insulated copper wire on plastic spool

Datalogger LabQuest-Mini
LQMINI

LabQuest Mini (Model 2) brings the power of our award-winning LabQuest technology to teachers who don’t need the versatility of a standalone device. The perfect solution for educators collecting data with a Windows or Macintosh computer or a Chromebook, LabQuest Mini works with Graphical Analysis or Logger Pro 3 software for unparalleled power, analysis, and curricular support.

Key Features

  • 100 kHz maximum sampling rate gives you the unrivaled power of our LabQuest 3 interface.
  • Five sensor ports give you the flexibility to choose from over 70 compatible sensors.
Diffraction grating 100 lines/mm
22-551
Diffraction grating 300 lines/mm
22-339
Diffraction grating 600 lines/mm
22-711
Digital thermometer
30.1018
Delivery contentsPenetration probe thermometer, battery, instruction manual
Measuring range temperature-40...+200°C (-40...+392°F)
MaterialPlastic
Power consumptionBatteries
Batteries includedyes
Batteries1 x LR44 1.5 V
Dimensions(L) 20 x (B) 16 x (H) 205 mm
Weight29 g
Dual-Range Force Sensor
DFS-BTA

The Dual-Range Force Sensor is a general-purpose sensor for measuring pushing and pulling forces. Two ranges allow you to measure forces as small as 0.01 newtons and as large as 50 newtons. It can be used in a broad range of ways:

  • As a replacement for a hand-held spring scale
  • Mounted horizontally on a dynamics cart to study collisions
  • Mounted on a ring-stand to measure forces in a vertical direction
  • Collect data from two Force Sensors simultaneously to study Newton’s Third Law
Dynamics Cart and Track System
DTS

The Dynamics Cart and Track System provides students with the tools they need to explore kinematics, dynamics, momentum, and energy. This versatile system can also be easily adapted to study optics, color, and diffraction.

The Dynamics Cart and Track System is the core of every physics lab. Easily add our Motion Detector, Dual-Range Force Sensor, Wireless Dynamics Sensor System, Photogate, and Accelerometer to study Newton’s second law, acceleration on an inclined plane, momentum, and much more. Optimize your track with the addition of our Vernier Optics Expansion Kit, Color Mixer Kit, and Diffraction Apparatus.

This traditional cart and track system features an aluminum track (1.2 m or 2.2 m length), two low-friction, plastic carts, an ultra pulley, and all of the necessary attachment accessories. You may also purchase an upgrade kit to add an optical Motion Encoder Cart to your existing Dynamics Cart and Track System. See Motion Encoder Upgrade Kits »

We have redesigned our carts to provide added durability, versatility, and instructional value.

  • Four mass trays make it easy to vary the total cart mass.
  • Super-elastic trigger button allows for new types of collisions.
  • An anti-roll peg ensures that the cart rolls on the track but not off the table.
  • Top tray allows for easy attachment of sensors and masses.
  • Two cart colors (teal and grey) make it easier to discuss collisions.
Dynamometer 5N, flat type
22-539
31z7cHC-rYL._SY445_.jpgScale lenght 80mm
E10 Led bulb 4,5-12V
24-093

Suitable for replacing a standard E10 screw-base flashlight bulb. Introduce students to Light Emitting Diode (LED) technology and its uses in addition to incandescent bulbs. Voltage 4.5...12V, max power 0.25W. Dimensions: Ø11 x 28mm

Educational laser class 2
DL1102L

Class 2 teaching laser for use as a high intensity light source

especially for experiments on interference, diffraction and holography as well as interferometry;

Laser diode in a “compact” magnetic module;

Wavelength: 635 nm; optical output power: ≤ 1 mW;

for tripod mounting, the holder for “compact” modules DS617-1H is required;

Operating voltage: 3 V (plug-in power supply included)

Housing dimensions: 84 x 84 x 39 mm

Electric motor (AC/DC) set
P38051M

Working model of an electric motor for student experiments. By assembling this model, students become familiar with the components and structure of a motor. The simplicity of the model enables a transparent representation of the function of the motor. The permanent magnet can be replaced by an electromagnet, which allows the motor to be operated with both direct and alternating current. Of course, operation as a main or shunt motor is also possible! The drive shaft of the motor is equipped with a pulley.

The tools required to assemble the working model are included in the scope of delivery!

Voltage supply in DC operation: 1.5 ... 5 V

Voltage supply in AC operation: 6 ... 9 V

Dimensions (in plastic box): 133 x 104 x 42 mm

Dimensions (finished model): 133 x 104 x 100 mm

Mass: approx. 277 g

Electric motor 0-5V, DC
KW-GEN

Can be used as both a motor and a generator in various DC experiments.

DC voltage: 0–5 V

Current: 0–0.3 A

Diameter: 32 mm

Cable length: 50 cm

Shaft diameter: 2 mm

Electric motor 2-6V / generator 1,5V on base
1196030

Electric motor 2-6V on base with rubber feet and 4 mm safety banana sockets. Can also be used as a electric generator. Produces 1.5 V with 90 mA at approx. 2500 rpm.

Electricity consumption meter
E305

Measure and compare the instantaneous and time-averaged power consumption of different network consumers in the school (e.g. LED bulb vs. incandescent bulb, desktop computer vs. laptop, kettle vs. heating coil, etc.).

Calculates accurately also non-resistive loads

Consumed electricity meter (2 tariffs)

LCD display

8 different options for displaying electrical parameters

options: current, real power, power factor, line power, line voltage, frequency, total cost, time the device was turned on

memory reset function

safe input/output sockets

operating voltage: 230VAC / 50Hz

current measurement: 190 ~ 250VAC (± 3%)

current measurement: 0.01 ~ 16A

measurement accuracy: ± 1% (@ resistive load)

clock accuracy: ± 1 minute/month

max. power: 3600W / 16A

frequency range: 45 ~ 65Hz

collectible power display: 0 ~ 9999.9 kWh

operating temperature: 10°C ~ 40°C

energy display: 0 ~ 999.9kWh

longest consumption recording time: 9999h

backup power: 3 x LR44 (V13GA or V13GAC included)

battery life: ± 3 months without mains power

device's own power consumption @ 220V: < 0.3W

Electromagnet, U-shaped
26-008

Electromagnet for voltage 4...6V

Filament bulb 4V, E10
29-001
22692.jpgVoltage 4V, current 0,3A.
Force and Acceleration Sensor, wireless
GDX-FOR

Specifications

  • Force: ±50 N
  • Acceleration: 3 axis, ±16 g
  • Gyroscope: 3 axis, 2000°/s
  • Connections:
    • Wireless: Bluetooth
    • Wired: USB
Friction coefficient research kit with inclined surface
22-227

The set includes a board with adjustable inclination, friction pads, a bowl for loads, and a rope.

Gas Pressure Sensor with syringe
GPS-BTA

The Gas Pressure Sensor can be used to monitor pressure changes in a gas. The range is wide enough to perform Boyle’s law yet it is sensitive enough to conduct vapor-pressure or pressure-temperature experiments. Biology teachers can use the Gas Pressure Sensor to monitor transpiration or respiration in an enclosed environment.

Gas Pressure Sensor, wireless
GDX-GP

Use Go Direct Gas Pressure Sensor to monitor gas pressure in a variety of experiments. It records accurate absolute pressure readings relative to the perfect vacuum reference point inside the sensor, allowing you to go below atmospheric pressure or up to 400 kPa. Easily change the displayed units to any one of seven options (kPa, mmHg, inHg, mbar, psi, atm, torr). Includes a syringe, tubing, and stoppers to ease setup for experiments such as Boyle’s law.

The Go Direct Gas Pressure Sensor can be used in a variety of experiments:

  • Investigate Boyle’s law and Charles’ law.
  • Investigate grip strength and muscle fatigue (using Gas Pressure Bulb, not included).
  • Measure the production of oxygen gas produced when hydrogen peroxide is destroyed by the enzyme catalase.
  • Monitor plant transpiration.

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

Glass prism
22-343

Material: glass. For studying the refraction of light. Dimensions: 38x38x38mm, height 30mm.

Hanging weight 100g
DM1215A

Color-coated weight piece with two hooks for hanging together,

with screen-printed, highly visible mass information, ideal for demonstration experiments

Tolerance: ±1%, powder-coated yellow

Hanging weight 100g, cylindrical
DM1215B

Hooked weight with robust hook and eyelet for hanging together;

Nickel-plated metal weight, with stamped weight number,

Hook for rods up to 10 mm diam, eyelet on the bottom for hanging several weights together

D = 25 mm, L (total) = approx. 70 mm

Iron nails, 150g
P34101N

For experiments on magnetism and electromagnetism (long-distance effect of a magnet, magnetic influence, magnetic force of a current-carrying coil).

Iron nails, galvanized, packed in a tin with a lid

Length of nails: approx. 20 mm

Filling quantity: approx. 150 g

Dimensions (tin): D=77 mm, H=36 mm

Weight (total): approx. 166 g

Iron plate 85x25x1mm
51754
Iron powder 100g
22-302

For experiments with magnets. In a plastic cup.

Iron wire 0,2mm/30m
P33161E

To investigate the dependence of electrical resistance on material, length, cross-section and temperature, to determine the specific resistance;

Conductor wire wound on a coil body

Material: Fe

Diameter: 0.2 mm

Wire length: 30 m

Mass: approx. 15 g

Iron wire 0,3mm/100m
1000950
Joule calorimeter universal
P27002D

For determining the specific heat of water, the heat output and current, the electrical heat equivalent, the water value of a vessel, the heat capacities of liquid and solid substances and for converting electrical energy into thermal energy.

Consisting of 2 aluminum cups, an insulated container in between, transparent lid with immersion heater cascade 2 / 4 / 6 Ohm with four 4mm safety sockets, silicone stopper for inserting a thermometer and a simple stirrer

Supply voltage: 6 V

Filling volume: approx. 150 and 700 ml

Dimensions: D = approx. 100 (105) mm, H = approx. 120 mm (without stirrer)

Mass: approx. 228 g

Knife switch, low voltage
22-112

With 4mm pin sockets.

LabQuest3 datalogger
LQ3
The all-new LabQuest 3 is a standalone data-collection platform that students can use to collect, analyze, and interact with data efficiently. With its new capacitive touch screen, students can navigate the platform with ease, and because of its wireless capabilities, students can collect data anywhere with LabQuest 3.
  • Connects wirelessly to the entire family of Go Direct® sensors
  • Easy-to-use platform enables students to generate graphs and analyze results
  • An excellent choice for laboratories, classrooms, or in-the-field investigations

Key Features

  • Full-featured data-collection platform
  • Compatible with all Vernier sensors
  • Large, high-resolution color screen
  • Touch navigation utilizing gestures
  • Fast data collection with 100,000 samples per second
  • Rechargeable, high-capacity battery
  • Built-in GPS and microphone
  • Wireless connectivity with Wi-Fi and Bluetooth® wireless technology
  • Built-in apps include Calculator, Periodic Table, Sound Recorder, Stopwatch, and more
  • Student instructions for over 75 of our most popular experiments included

Connectivity to Chromebooks, Computers, iPad® tablets, and Mobile Devices

Students can share real-time data with multiple devices for a truly hands-on, collaborative learning experience. Use LabQuest 3 to transfer data wirelessly to computers, Chromebooks, or mobile devices running Graphical Analysis.

USB Sensor Interface

If you want to use your own computer or Chromebook to collect data, use LabQuest 3 as a conduit between our LabQuest sensors and these devices. LabQuest 3 works as a USB sensor interface with our Logger Pro® software or Graphical Analysis app.

Laser illuminator (1 beam, red) for optics experiments
210501

Provides a single beam that is visible in the horizontal plane. Specification: Laser type: diode. Wavelength: 635 nm. Power/class: Pmax < 1mW / 2. Dimensions: 80 x 25 x 20 mm. Power supply: 3V DC / 50 mA. Comes with a tray that holds 2xAA batteries.

LED bulb 2,5-6V, E10
22-708

Suitable to replace a standard E10 screw-base flashlight bulb. Introduce students to Light Emitting Diode (LED) technology and its uses in addition to incandescent bulbs. Voltage 2.5...6V, max power 0.12W. Dimensions: Ø11 x 28mm

Light source LED/laser
47535

Switchable light from white LED and red laser. Both light sources are certified with the lowest protection class of their kind, the device is assigned to risk group RG0 (“free group”) according to DIN EN 62471 and laser protection class I according to DIN EN 60825.

Loads of various weights on a suspended base
P11202S

For the quick assembly of various compact "mass packages";

Disc weight set with plate, consisting of:

1 x plate for slotted weights, 10 g, SE

2 x slotted weight 5 g, SE

3 x slotted weight 20 g, SE

3 x slotted weight 50 g, SE

2 x slotted weight 10 g, SE

Material: nickel-plated steel

Tolerance: ±1%

Dimensions: 113 x 55 x 35 mm

Weight: 250 g

Magnetic Field Sensor
MG-BTA

This sensor uses a Hall effect transducer, and measures a vector component of the magnetic field near the sensor tip. It has two ranges, allowing for measurement of relatively strong magnetic fields around permanent magnets and electromagnets, as well as measurement of weak fields such as the Earth’s magnetic field. The articulated sensor tip allows you to measure both transverse and longitudinal magnetic fields.

Magnetic needle on base l=100mm
22-471
22471.jpgh=140mm
Magnetic needle on base, 75mm
86078IN
Measuring tape 5m
22-403
Motion detector
MD-BTD

The Motion Detector uses ultrasound to measure the position of carts, balls, people, and other objects.

Measure objects as close as 15 cm and as far away as 6 m.

Sensitivity switch reduces noise and produces higher quality data for studying dynamics carts on tracks.

Attaches easily to the Vernier Dynamics System.

Pivoting head allows for flexibility in the experiment setup.

You may also want to purchase the Motion Detector Clamp to attach the Motion Detector to a variety of objects such as table tops, ring stands, etc.

Motion Detector, wireless
GDX-MD

Specifications

  • Range: 15 cm to 3.5 m
  • Resolution: 1 mm
  • Maximum sampling rate: 30 samples/s
  • Connections:
    • Wireless: Bluetooth
    • Wired: USB
Multimeter DT890B, digital
22-360

Digital tester - multimeter with many functions (current, voltage, resistance, Cx, hFE, diode).

Function Range Accuracy

DC voltage 200mV-1000V ±(0.5%+1dgt)

AC voltage 200mV-750V ±(1.2%+3dgt)

DC current 20µA-20A ±(2.0%+1dgt)

AC current 20µA-20A ±(2.0%+3dgt)

Resistance 200Ω-200MΩ ±(1.0%+1dgt)

Diode test

Transistor test

Buzzer

Dimensions 170×87×35mm

Power supply 9V battery 6F22

Weight 210g

Multimeter, analog, electronically protected
P321220

Multimeter for measuring voltage and current, DC and AC, can also be used as a galvanometer. As an ideal student multimeter, it has two double scales.

All of this makes this device unique:

Electronic overload protection in all measuring ranges, with control LED display (no more fuses!)

Large, robust design with holster

Easy to read thanks to tilted position

Transparent base with recessed grip for holding with one hand

1 mV final value range for measuring thermal and induction voltages without a preamplifier

All measuring ranges (even low currents!) are available in AC

Unusually good frequency response: typically -1.5 db at 20 kHz, so measurements on all types of resonant circuits are also possible directly

Large, easy-to-read mirror scale with clear print

Extremely accurate, typically 1.5%

Large, robust selector switch

10 A range with its own input socket

Center zero point can be selected by switch position

Technical data:

AC and DC voltage ranges: 1, 100, 300 mV, 1, 3, 10, 30 V

AC current ranges and DC: 100 µA, 10, 30, 100, 300 mA, 1, 10 A

Internal resistance: 100 kOhm/V

Selector switch: DC, AC, battery control, pointer center position

Scale arc length: approx. 90 mm

Power supply: 4 x 1.5 V Mignon batteries (included)

Dimensions: approx. 200 x 140 x 110 mm

Weight: approx. 637 g

Multimeter, digital, with automatic range selection
25-010

DC voltage 200mV...600V

AC voltage 200V, 600V

DC and AC current 200mkA...10A

Resistance 200 Ohm...20Mohm

Diode test

Buzzer

Backlit. Powered by 2xAAA batteries. Automatic power off.

Neodymium magnet 8x8x4mm
24-336
Nylon cord 1mm/20m
48187

Length: 20 m

Diameter: 1 mm

Load capacity: 28 kg

Photogate
VPG-BTD

Modes: digital status, movement, length of passing object, consecutive gates, pendulum from the center and "gates and object". Grip distance 75mm, Reaction time 5 ms.

Tripod mount included.

Works with LabQuest, LabQuest2, LabQuest3, LabQuestMini and LabQuest Stream data collectors. Does not work with GoLink data collector!

Photogate, wireless
GDX-VPG

Using Go Direct Photogate, students are able to easily and accurately measure velocity and acceleration to study the movement of an object in free fall, rolling objects, collisions, and pendulums, without needing to know anything about the geometry of the object.

Go Direct Photogate also includes a single laser gate for use with objects passing outside of the arms of the sensor. Using the laser gate requires a visible-light pen laser (not included).

Go Direct Photogate can be used in a variety of experiments:

  • Measuring acceleration of a cart on an incline using a cart picket fence
  • Measuring the angular motion of a wheel as it is turning
  • Investigating Newton’s second law using a half-Atwood machine to measure acceleration
  • Determining the time an object passes one or more gates

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

Plane-parallel glass block for plane-parallel optics experiments
22-342

Cuboid 75x50x18mm.

Plastic ball d60mm for mechanics experiments
DM3605R

Ball D=60 mm, for dynamics and momentum conservation

Pocket compass
42.1000

Made of plastic, dimensions 37x43x12mm, weight 6g. Equipped with a hanging loop.

Made in Germany

Polarization discs, 2 pcs, d210mm
26-028

The set includes a wooden stand and two freely rotating polaroids with a diameter of 21 cm. By turning the polaroids relative to each other, the light can be "faded".

Polaroids 5x5cm in frame, 2 pcs
MT03256
Power supply 3-12V, 1,5A
DC15A312V

Power supply with fixed output voltages 3; 4.5; 6; 7.5; 9 and 12V.

Load max 1.5A. Overload protection.

Lightweight, pulse-switched laboratory power supply to replace batteries.

Dimensions 180x80x110mm.

Weight 460g.

Power supply AC/DC 3A, 0-12V, with analog display
ACDCT3A12V

Laboratory power supply. AC and DC voltage. Current 3A, voltage 0-12V continuously variable for DC voltage. Fixed AC voltage outputs 3V; 6V; 9V and 12V. Analog voltmeter on the front panel. Includes 4 pcs. 1m connection cables with 4mm connectors.

Power supply DC voltage 1.5...15V, 1.5A
55223

In a ventilated sheet steel housing with on/off switch and power cable, colored 4 mm safety connection sockets for DC voltage, continuously adjustable output voltage, stabilized and smoothed, overheating and short-circuit protection, moving coil voltmeter. All outputs galvanically isolated from the mains.

Approved for student experiments in accordance with the current directive on safety in teaching (RiSU). CE mark.

Resistor 10 ohm
22-606

Equipped with sockets for 4mm banana plugs.

Resistor 100 ohm on base
1196056

Resistance 100 Ω / 10 W ±1% on base with rubber feet and 4 mm safety banana sockets.

Resistor 5 ohm
22-605
22606.jpgEquipped with sockets for 4mm banana plugs.
Resistors on base
15007
A variety kinds of resistance MS320.4_l.jpg

Resistors 5, 10, 15, 200, 470 ohms and 1, 2, 10, 50, 100 kilo-ohms.

Resistors, 10/50/100 Ohm, with sockets
54535

Windings visible, on base with 4 mm connection sockets.

Rheostat 10 Ohm
22-185

For current up to 2 A. With sockets for 4mm pin connectors.

Screen 90x90mm on base
13707/13733
Screen for experiments in optics, 12x13cm
22-626

Plastic screen with base. Dimensions 120 x 130 mm. Base height 23mm.

Set of 4 balls
P33085K

For experiments on swimming, floating and sinking in water, also in mechanics;

Material: wood, glass, steel, styrofoam

Diameter of the balls: approx. 20 mm each

Mass of the balls: approx. 37 g

Packed in a plastic container with lid

Dimensions: 55 x 55 x 40 mm

Mass: approx. 48 g

Set of different wires
DE3309S

1 roll of wire, D=0.1 mm, L=30 m

1 roll of iron wire, D=0.2 mm, L=30 m

1 roll of copper wire, D=0.2 mm, L=30 m

1 roll of constantan wire, D=0.2 mm, L=30 m

1 roll of constantan wire, D=0.5 mm, L=15 m

1 box with lid

Set of electrodes, 6 pcs
27-039

Al, Zn, Pb, Cu, Brass, Fe. Dimensions 75x24x3mm, equipped with screw terminals.

Sliding resistor 20 Ohm
DE7209S

Sliding resistor in an open design so that the sliding slider on the resistance wire winding is clearly visible,

with 3 sockets for safety and normal laboratory cables with 4 mm plugs;

Resistance: 20 Ohm, load capacity: 2 A (also higher for a short time), voltage: max. 42 V,

Dimensions: approx. 150 x 65 x 40 mm

Solar cell 1V, 200mA
P36001S

For experiments on photovoltaics and solar technology, for converting radiation energy (sunlight) directly into electrical energy;

Polycrystalline solar cell with sealed surface, two connection cables with crocodile clips, copper tracks on the back for soldering, poles marked

Technical data:

Voltage: 1.0 V

Current: 200 mA

Power: 0.2 W

Length of cables: approx. 20 cm each

Dimensions: 75 x 45 x 3 mm

Weight: 18 g

Solar cell 2V, on stand
22-175

2V, 110mA, 4-mm sockets.

Spring set, different stiffness, 5 parts
22-213

2 N/m, 13 N/m, 22 N/m, 36 N/m and 50 N/m

Stand h=50cm
22-216

The 5x8" stand consists of a 130x200mm base and a 50cm long rod.

Steel ball 30mm
1002939
stainlessball.jpgMass 100g
Stopwatch, digital
22-046

Digital stopwatch with clock. Main numbers height 8mm.

Stopwatch, mechanical, with one button
22-045

Classic mechanical stopwatch.

Large circle 30 seconds, small circle 15 minutes.

Student ammeter, protected
P32201A

Analogue hand-held measuring device for current (ammeter), especially suitable for student experiments thanks to electronic overload protection.

Technical data:

Measuring ranges DC and AC: 10, 30, 100, 300 mA, 1, 3, 10 A

Selector switch: DC, AC, battery check, off

Moving coil measuring mechanism with mirror scale, arc length: approx. 90 mm

Overload protection with diodes and LED display

Accuracy: 2% (DC), 3% (AC)

Own consumption: 100 mW (+ fuse)

Usable frequency range for AC: 15 Hz ... 20 kHz

Maximum permissible input voltage: 30 Veff

Power supply: 4 x AA batteries

(Battery life: approx. 3 years)

Dimensions: approx. 200 x 140 x 100 mm

Weight: approx. 630 g

Student voltmeter, protected
P32201V

Analogue hand-held voltage measuring device, especially suitable for student experiments thanks to electronic overload protection.

Technical data:

Measuring ranges DC and AC: 100, 300 mV, 1, 3, 10, 30 V

Selector switch: DC, AC, battery check, off

Moving coil measuring device with mirror scale

Arc length: approx. 90 mm

Overload protection with diodes

Accuracy: 2% (DC), 3% (AC)

Internal resistance: 100 kOhm/V

Usable frequency range for AC: 15 Hz ... 20 kHz

Maximum permissible input voltage: 30 Veff

Power supply: 4 x AA batteries (battery life: approx. 3 years)

Dimensions: approx. 200 x 140 x 100 mm

Weight: approx. 600 g

Towed doubled test body for studying the coefficient of friction
DM6802S

For experiments on static, sliding and rolling friction,

by "unfolding" the block, the wood friction surface can be doubled;

Wooden block with four different surfaces: wood, rubber, leather and sandpaper, one end with a pull cord

Dimensions: 40x40x160 mm

Weight: approx. 200 g

Towed test body for studying the coefficient of friction
DM6802R

For tests on static, sliding and rolling friction;

Painted wooden block with hook, a hook on the front for hanging a force gauge,

a central hole for stability tests

Dimensions: 160x80x40 mm, weight: approx. 350 g

U-magnet 130x80mm, AlNiCo
22-475
U-magnet 65mm AlNiCo
22-075

Material AlNiCo. Strong U-magnet with dimensions 66x53x(20x6)mm

USB motion sensor
GO-MOT
product.go-mot._physics._hs._features.001.590.332.jpgGo!Motion is used to collect position, velocity and acceleration data of moving objects. Go!Motion’s USB port allows for direct connection to a computer’s USB port, which simplifies experiment set up. Students learn experientially as they graph the motion of a ball, a cart on a ramp, pendulum motion, or themselves. Go!Motion is easy to use, allowing students to focus on learning scientific concepts instead of setting up the lab. Go!Motion’s head pivots to match the needs of your lab. Flip the head halfway for monitoring the motion of a cart on a track, or flip 180° to record motion data from a tripod. Use the metal screw mount to attach the Go!Motion to a track, such as the Vernier Dynamics System, for studies of velocity and acceleration. Go!Motion features reduced noise and automatic temperature compensation to ensure motion readings are continuously accurate. The sensitivity switch lets you customize settings to your experiment. Measure motion data as close as 15 cm and as far away as 6 m!
Vernier calliper, digital
22-186

Digital caliper 0..15 cm, 0.01mm

Voltmeter 0...3V and 0...15V, DC
22-008
Voltmeter 0...5V, 0...10V and 0...15V, DC
22-009
Voltmeter, DC and AC, analog
1172039

DC voltage: 0.1 / 1 / 10 / 100 / 1000 V, accuracy 2% of full scale

AC voltage: 3 / 10 / 100 / 1000 V, accuracy 3% of full scale

Internal resistance DC: 2kΩ (0.1 V) to 20 MΩ (1000 V)

Internal resistance DC: 27kΩ (3 V) to 9 MΩ (1000 V)

Display: moving coil instrument with mirror scale

Zinc plate 85x25x1mm
51752
accbtaj.jpg25-g Accelerometer

Specifications

  • Power: 30 mA @ 5 VDC
  • Range: ±245 m/s² (±25g)
  • Accuracy: ±2.45 m/s² (±0.25g)
  • Frequency Response: 0–100 Hz
  • Typical Resolution: 0.16 m/s²
191,54
gdx3mg.jpg3-Axis Magnetic Field Sensor

The Go Direct 3-Axis Magnetic Field Sensor measures the components of the magnetic field along three orthogonal axes. This allows you to determine the magnitude and direction of the magnetic field at any point in space. If desired, measure the field along only two axes, or even one axis, choosing the direction that is best for the experiment.

The Go Direct 3-Axis Magnetic Field Sensor can be used in a variety of experiments:

  • Quantify the magnetic field strength of induced magnets.
  • Determine the declination and inclination of the Earth’s magnetic field at your location using vector components.
  • Investigate the relationship between magnetic field strength, coils per unit length, and current in the center of a solenoid.

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

172,02
product.gdx-acc._hero.001-600x338.jpgAcceleration sensor with altimeter, wireless

This 3-axis acceleration sensor has two acceleration ranges plus an altimeter and a 3-axis gyroscope. An additional channel measures the angle of the sensor’s long axis.

  • Measure helmet impacts in concussion-related investigations.
  • Slip it into your pocket and pirouette or ride a half-pipe.
  • Mount this accelerometer on your bicycle or affix it to your lab cart without any dragging cables.

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

200,08
1172038.jpgAmmeter, DC and AC, analog

Direct current: 1 / 10 / 100 / 100 mA / 1 A / 10 A, accuracy 2% of full scale

Alternating current: 10 / 100 mA / 1 A / 10 A, accuracy 3% of full scale

DC voltage drop: 250 mV in all ranges

AC voltage drop: 5V (10 mA), 500 mV (100 mA), 50 mV (1 A / 10 A)

Display: moving coil instrument with mirror scale

95,00
A54870.jpgAnalog multimeter

Analogue multimeter with mirror scale, tip-mounted moving coil measuring mechanism and central measuring range rotary switch.

For measuring current, voltage and resistance

20 measuring ranges

Continuity test with acoustic signal

Includes accessories: case, test leads, batteries and operating instructions.

Voltage DC: 3/15/60/150/600 V; ±3.0%

Voltage AC: 15/60/150/600 V; ±4.0%

Current DC: 100 µA/10 mA/500 mA/10 A; ±3.0%

Current AC: 10 mA/500 mA/10 A; ±4.0%

Resistance: 200 Ohm/2/20/200 kOhm/2 MOhm; ±5.0%

Power supply: 3 x 1.5 V AAA batteries

Display: 75 mm mirror scale

Safety: EN 61010-1; CAT II 600 V

Dimensions: 110 x 175 x 45 mm

Weight: 315 g

52,64
alnicosmall.jpgBar magnet 74x11x6mm, AlNiCo

Small, strong I-magnet made of AlNiCo material.

9,76
9Vpatarei.jpgBattery 9V
6LR61
3,66
27027.jpgBulb and motor model, DC

Motor operating voltage 1...6V, bulb operating voltage 6V. Sockets for 4mm connectors.

11,51
4748-2.jpgCables with magnetic tips, 10 pcs

Connecting wires with magnetic tips make it easy to build a circuit. The batteries and bulb socket shown in the picture are not included. The set consists of 10 connecting wires.

17,08
U8441020_01_Calorimeter-with-Heating-Coil-150-ml.jpgCalorimeter 200ml, aluminium

200ml, heating 6V, heating element resistance 2...3 ohms. Aluminum shell d100mm x h100mm, aluminum container 70xd60mm inside. Insulated with polystyrene foam, heating elements with two 4mm pin sockets.

20,00
track.jpgCombination 1.2 m Track/Optics Bench

The Combination Dynamics Track and Optical Bench is aluminum and includes a metric scale. Extremely rigid, this 1.2 meter track will not sag under use. The track includes 2 Adjustable Two Foot Levelers.

278,16
p71001a.jpgComposite nylon cord 60m

Material: composite nylon

60 linear meters of cord, on a roll with side clamping grooves

Dimensions of the roll: D=22 mm, L=43 mm

Weight: approx. 7 g

5,68
22030.jpgConnecting cable 50 cm

Length 50 cm. Available in different colors, wires are with extendable 4mm banana connectors.

2,93
juhtmed.jpgConnection cable 25 cm, 4mm banana plugs

Length 25 cm. Available in different colors, wires are with extendable 4mm connectors.

2,68
P33161C.jpgConstantan wire 0,2mm/30m

To investigate the dependence of electrical resistance on material, length, cross-section and temperature, to determine the specific resistance;

Resistance wire wound on a coil body

Material: NiCr

Diameter: 0.2 mm

Wire length: 30 m

Mass: approx. 9 g

6,00
1000949.jpgCupper wire 0,3mm, 100m

Insulated copper wire on plastic spool

14,64
lqmini1.jpgDatalogger LabQuest-Mini

LabQuest Mini (Model 2) brings the power of our award-winning LabQuest technology to teachers who don’t need the versatility of a standalone device. The perfect solution for educators collecting data with a Windows or Macintosh computer or a Chromebook, LabQuest Mini works with Graphical Analysis or Logger Pro 3 software for unparalleled power, analysis, and curricular support.

Key Features

  • 100 kHz maximum sampling rate gives you the unrivaled power of our LabQuest 3 interface.
  • Five sensor ports give you the flexibility to choose from over 70 compatible sensors.
315,98
301018gross.jpgDigital thermometer
Delivery contentsPenetration probe thermometer, battery, instruction manual
Measuring range temperature-40...+200°C (-40...+392°F)
MaterialPlastic
Power consumptionBatteries
Batteries includedyes
Batteries1 x LR44 1.5 V
Dimensions(L) 20 x (B) 16 x (H) 205 mm
Weight29 g
25,48
dfs-bta_web.jpgDual-Range Force Sensor

The Dual-Range Force Sensor is a general-purpose sensor for measuring pushing and pulling forces. Two ranges allow you to measure forces as small as 0.01 newtons and as large as 50 newtons. It can be used in a broad range of ways:

  • As a replacement for a hand-held spring scale
  • Mounted horizontally on a dynamics cart to study collisions
  • Mounted on a ring-stand to measure forces in a vertical direction
  • Collect data from two Force Sensors simultaneously to study Newton’s Third Law
213,50
product.dts._hero.001.590.332.jpgDynamics Cart and Track System

The Dynamics Cart and Track System provides students with the tools they need to explore kinematics, dynamics, momentum, and energy. This versatile system can also be easily adapted to study optics, color, and diffraction.

The Dynamics Cart and Track System is the core of every physics lab. Easily add our Motion Detector, Dual-Range Force Sensor, Wireless Dynamics Sensor System, Photogate, and Accelerometer to study Newton’s second law, acceleration on an inclined plane, momentum, and much more. Optimize your track with the addition of our Vernier Optics Expansion Kit, Color Mixer Kit, and Diffraction Apparatus.

This traditional cart and track system features an aluminum track (1.2 m or 2.2 m length), two low-friction, plastic carts, an ultra pulley, and all of the necessary attachment accessories. You may also purchase an upgrade kit to add an optical Motion Encoder Cart to your existing Dynamics Cart and Track System. See Motion Encoder Upgrade Kits »

We have redesigned our carts to provide added durability, versatility, and instructional value.

  • Four mass trays make it easy to vary the total cart mass.
  • Super-elastic trigger button allows for new types of collisions.
  • An anti-roll peg ensures that the cart rolls on the track but not off the table.
  • Top tray allows for easy attachment of sensors and masses.
  • Two cart colors (teal and grey) make it easier to discuss collisions.
603,90
31z7cHC-rYL._SY445_.jpgDynamometer 5N, flat type
Scale lenght 80mm
8,54
22708.jpgE10 Led bulb 4,5-12V

Suitable for replacing a standard E10 screw-base flashlight bulb. Introduce students to Light Emitting Diode (LED) technology and its uses in addition to incandescent bulbs. Voltage 4.5...12V, max power 0.25W. Dimensions: Ø11 x 28mm

2,44
DL1102L1.jpgEducational laser class 2

Class 2 teaching laser for use as a high intensity light source

especially for experiments on interference, diffraction and holography as well as interferometry;

Laser diode in a “compact” magnetic module;

Wavelength: 635 nm; optical output power: ≤ 1 mW;

for tripod mounting, the holder for “compact” modules DS617-1H is required;

Operating voltage: 3 V (plug-in power supply included)

Housing dimensions: 84 x 84 x 39 mm

95,16
motormodellbausatz2.jpgElectric motor (AC/DC) set

Working model of an electric motor for student experiments. By assembling this model, students become familiar with the components and structure of a motor. The simplicity of the model enables a transparent representation of the function of the motor. The permanent magnet can be replaced by an electromagnet, which allows the motor to be operated with both direct and alternating current. Of course, operation as a main or shunt motor is also possible! The drive shaft of the motor is equipped with a pulley.

The tools required to assemble the working model are included in the scope of delivery!

Voltage supply in DC operation: 1.5 ... 5 V

Voltage supply in AC operation: 6 ... 9 V

Dimensions (in plastic box): 133 x 104 x 42 mm

Dimensions (finished model): 133 x 104 x 100 mm

Mass: approx. 277 g

22,69
productkwgen.jpgElectric motor 0-5V, DC

Can be used as both a motor and a generator in various DC experiments.

DC voltage: 0–5 V

Current: 0–0.3 A

Diameter: 32 mm

Cable length: 50 cm

Shaft diameter: 2 mm

11,57
1196030.jpgElectric motor 2-6V / generator 1,5V on base

Electric motor 2-6V on base with rubber feet and 4 mm safety banana sockets. Can also be used as a electric generator. Produces 1.5 V with 90 mA at approx. 2500 rpm.

24,00
e305.jpgElectricity consumption meter

Measure and compare the instantaneous and time-averaged power consumption of different network consumers in the school (e.g. LED bulb vs. incandescent bulb, desktop computer vs. laptop, kettle vs. heating coil, etc.).

Calculates accurately also non-resistive loads

Consumed electricity meter (2 tariffs)

LCD display

8 different options for displaying electrical parameters

options: current, real power, power factor, line power, line voltage, frequency, total cost, time the device was turned on

memory reset function

safe input/output sockets

operating voltage: 230VAC / 50Hz

current measurement: 190 ~ 250VAC (± 3%)

current measurement: 0.01 ~ 16A

measurement accuracy: ± 1% (@ resistive load)

clock accuracy: ± 1 minute/month

max. power: 3600W / 16A

frequency range: 45 ~ 65Hz

collectible power display: 0 ~ 9999.9 kWh

operating temperature: 10°C ~ 40°C

energy display: 0 ~ 999.9kWh

longest consumption recording time: 9999h

backup power: 3 x LR44 (V13GA or V13GAC included)

battery life: ± 3 months without mains power

device's own power consumption @ 220V: < 0.3W

24,40
uelmg.jpgElectromagnet, U-shaped

Electromagnet for voltage 4...6V

24,40
22692.jpgFilament bulb 4V, E10
Voltage 4V, current 0,3A.
1,01
product.gdx-for._hero.001-600x337.jpgForce and Acceleration Sensor, wireless

Specifications

  • Force: ±50 N
  • Acceleration: 3 axis, ±16 g
  • Gyroscope: 3 axis, 2000°/s
  • Connections:
    • Wireless: Bluetooth
    • Wired: USB
207,40
222271.jpgFriction coefficient research kit with inclined surface

The set includes a board with adjustable inclination, friction pads, a bowl for loads, and a rope.

47,58
product.gps-bta._hero.003.590.332.jpgGas Pressure Sensor with syringe

The Gas Pressure Sensor can be used to monitor pressure changes in a gas. The range is wide enough to perform Boyle’s law yet it is sensitive enough to conduct vapor-pressure or pressure-temperature experiments. Biology teachers can use the Gas Pressure Sensor to monitor transpiration or respiration in an enclosed environment.

179,10
product.gdx-gp._hero.001-600x338.jpgGas Pressure Sensor, wireless

Use Go Direct Gas Pressure Sensor to monitor gas pressure in a variety of experiments. It records accurate absolute pressure readings relative to the perfect vacuum reference point inside the sensor, allowing you to go below atmospheric pressure or up to 400 kPa. Easily change the displayed units to any one of seven options (kPa, mmHg, inHg, mbar, psi, atm, torr). Includes a syringe, tubing, and stoppers to ease setup for experiments such as Boyle’s law.

The Go Direct Gas Pressure Sensor can be used in a variety of experiments:

  • Investigate Boyle’s law and Charles’ law.
  • Investigate grip strength and muscle fatigue (using Gas Pressure Bulb, not included).
  • Measure the production of oxygen gas produced when hydrogen peroxide is destroyed by the enzyme catalase.
  • Monitor plant transpiration.

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

182,57
22343.jpgGlass prism

Material: glass. For studying the refraction of light. Dimensions: 38x38x38mm, height 30mm.

6,10
DM1215A1.jpgHanging weight 100g

Color-coated weight piece with two hooks for hanging together,

with screen-printed, highly visible mass information, ideal for demonstration experiments

Tolerance: ±1%, powder-coated yellow

28,60
DM1215B.jpgHanging weight 100g, cylindrical

Hooked weight with robust hook and eyelet for hanging together;

Nickel-plated metal weight, with stamped weight number,

Hook for rods up to 10 mm diam, eyelet on the bottom for hanging several weights together

D = 25 mm, L (total) = approx. 70 mm

6,40
eisennagelindose.jpgIron nails, 150g

For experiments on magnetism and electromagnetism (long-distance effect of a magnet, magnetic influence, magnetic force of a current-carrying coil).

Iron nails, galvanized, packed in a tin with a lid

Length of nails: approx. 20 mm

Filling quantity: approx. 150 g

Dimensions (tin): D=77 mm, H=36 mm

Weight (total): approx. 166 g

5,70
22302.jpgIron powder 100g

For experiments with magnets. In a plastic cup.

7,67
P33161E.jpgIron wire 0,2mm/30m

To investigate the dependence of electrical resistance on material, length, cross-section and temperature, to determine the specific resistance;

Conductor wire wound on a coil body

Material: Fe

Diameter: 0.2 mm

Wire length: 30 m

Mass: approx. 15 g

5,00
joulekalorimeteruniversal.jpgJoule calorimeter universal

For determining the specific heat of water, the heat output and current, the electrical heat equivalent, the water value of a vessel, the heat capacities of liquid and solid substances and for converting electrical energy into thermal energy.

Consisting of 2 aluminum cups, an insulated container in between, transparent lid with immersion heater cascade 2 / 4 / 6 Ohm with four 4mm safety sockets, silicone stopper for inserting a thermometer and a simple stirrer

Supply voltage: 6 V

Filling volume: approx. 150 and 700 ml

Dimensions: D = approx. 100 (105) mm, H = approx. 120 mm (without stirrer)

Mass: approx. 228 g

31,00
lylmp.jpgKnife switch, low voltage

With 4mm pin sockets.

5,05
labq33.jpgLabQuest3 datalogger
The all-new LabQuest 3 is a standalone data-collection platform that students can use to collect, analyze, and interact with data efficiently. With its new capacitive touch screen, students can navigate the platform with ease, and because of its wireless capabilities, students can collect data anywhere with LabQuest 3.
  • Connects wirelessly to the entire family of Go Direct® sensors
  • Easy-to-use platform enables students to generate graphs and analyze results
  • An excellent choice for laboratories, classrooms, or in-the-field investigations

Key Features

  • Full-featured data-collection platform
  • Compatible with all Vernier sensors
  • Large, high-resolution color screen
  • Touch navigation utilizing gestures
  • Fast data collection with 100,000 samples per second
  • Rechargeable, high-capacity battery
  • Built-in GPS and microphone
  • Wireless connectivity with Wi-Fi and Bluetooth® wireless technology
  • Built-in apps include Calculator, Periodic Table, Sound Recorder, Stopwatch, and more
  • Student instructions for over 75 of our most popular experiments included

Connectivity to Chromebooks, Computers, iPad® tablets, and Mobile Devices

Students can share real-time data with multiple devices for a truly hands-on, collaborative learning experience. Use LabQuest 3 to transfer data wirelessly to computers, Chromebooks, or mobile devices running Graphical Analysis.

USB Sensor Interface

If you want to use your own computer or Chromebook to collect data, use LabQuest 3 as a conduit between our LabQuest sensors and these devices. LabQuest 3 works as a USB sensor interface with our Logger Pro® software or Graphical Analysis app.

723,46
laser-line-box-with-power-supply.jpgLaser illuminator (1 beam, red) for optics experiments

Provides a single beam that is visible in the horizontal plane. Specification: Laser type: diode. Wavelength: 635 nm. Power/class: Pmax < 1mW / 2. Dimensions: 80 x 25 x 20 mm. Power supply: 3V DC / 50 mA. Comes with a tray that holds 2xAA batteries.

95,57
e10LED.jpgLED bulb 2,5-6V, E10

Suitable to replace a standard E10 screw-base flashlight bulb. Introduce students to Light Emitting Diode (LED) technology and its uses in addition to incandescent bulbs. Voltage 2.5...6V, max power 0.12W. Dimensions: Ø11 x 28mm

2,19
47535.jpgLight source LED/laser

Switchable light from white LED and red laser. Both light sources are certified with the lowest protection class of their kind, the device is assigned to risk group RG0 (“free group”) according to DIN EN 62471 and laser protection class I according to DIN EN 60825.

234,24
P11202S.jpgLoads of various weights on a suspended base

For the quick assembly of various compact "mass packages";

Disc weight set with plate, consisting of:

1 x plate for slotted weights, 10 g, SE

2 x slotted weight 5 g, SE

3 x slotted weight 20 g, SE

3 x slotted weight 50 g, SE

2 x slotted weight 10 g, SE

Material: nickel-plated steel

Tolerance: ±1%

Dimensions: 113 x 55 x 35 mm

Weight: 250 g

26,50
product.mg-bta._hero.002.590.332.jpgMagnetic Field Sensor

This sensor uses a Hall effect transducer, and measures a vector component of the magnetic field near the sensor tip. It has two ranges, allowing for measurement of relatively strong magnetic fields around permanent magnets and electromagnets, as well as measurement of weak fields such as the Earth’s magnetic field. The articulated sensor tip allows you to measure both transverse and longitudinal magnetic fields.

116,26
product.vds.md-btd._physics._hero.001.590.332.jpgMotion detector

The Motion Detector uses ultrasound to measure the position of carts, balls, people, and other objects.

Measure objects as close as 15 cm and as far away as 6 m.

Sensitivity switch reduces noise and produces higher quality data for studying dynamics carts on tracks.

Attaches easily to the Vernier Dynamics System.

Pivoting head allows for flexibility in the experiment setup.

You may also want to purchase the Motion Detector Clamp to attach the Motion Detector to a variety of objects such as table tops, ring stands, etc.

181,78
product.gdx-md._hero.001-600x338.jpgMotion Detector, wireless

Specifications

  • Range: 15 cm to 3.5 m
  • Resolution: 1 mm
  • Maximum sampling rate: 30 samples/s
  • Connections:
    • Wireless: Bluetooth
    • Wired: USB
224,40
DT-890B.jpgMultimeter DT890B, digital

Digital tester - multimeter with many functions (current, voltage, resistance, Cx, hFE, diode).

Function Range Accuracy

DC voltage 200mV-1000V ±(0.5%+1dgt)

AC voltage 200mV-750V ±(1.2%+3dgt)

DC current 20µA-20A ±(2.0%+1dgt)

AC current 20µA-20A ±(2.0%+3dgt)

Resistance 200Ω-200MΩ ±(1.0%+1dgt)

Diode test

Transistor test

Buzzer

Dimensions 170×87×35mm

Power supply 9V battery 6F22

Weight 210g

18,50
multimeteranalog2.jpgMultimeter, analog, electronically protected

Multimeter for measuring voltage and current, DC and AC, can also be used as a galvanometer. As an ideal student multimeter, it has two double scales.

All of this makes this device unique:

Electronic overload protection in all measuring ranges, with control LED display (no more fuses!)

Large, robust design with holster

Easy to read thanks to tilted position

Transparent base with recessed grip for holding with one hand

1 mV final value range for measuring thermal and induction voltages without a preamplifier

All measuring ranges (even low currents!) are available in AC

Unusually good frequency response: typically -1.5 db at 20 kHz, so measurements on all types of resonant circuits are also possible directly

Large, easy-to-read mirror scale with clear print

Extremely accurate, typically 1.5%

Large, robust selector switch

10 A range with its own input socket

Center zero point can be selected by switch position

Technical data:

AC and DC voltage ranges: 1, 100, 300 mV, 1, 3, 10, 30 V

AC current ranges and DC: 100 µA, 10, 30, 100, 300 mA, 1, 10 A

Internal resistance: 100 kOhm/V

Selector switch: DC, AC, battery control, pointer center position

Scale arc length: approx. 90 mm

Power supply: 4 x 1.5 V Mignon batteries (included)

Dimensions: approx. 200 x 140 x 110 mm

Weight: approx. 637 g

193,50
25010.jpgMultimeter, digital, with automatic range selection

DC voltage 200mV...600V

AC voltage 200V, 600V

DC and AC current 200mkA...10A

Resistance 200 Ohm...20Mohm

Diode test

Buzzer

Backlit. Powered by 2xAAA batteries. Automatic power off.

22,57
48187.jpgNylon cord 1mm/20m

Length: 20 m

Diameter: 1 mm

Load capacity: 28 kg

3,23
vpg-btd_web.jpgPhotogate

Modes: digital status, movement, length of passing object, consecutive gates, pendulum from the center and "gates and object". Grip distance 75mm, Reaction time 5 ms.

Tripod mount included.

Works with LabQuest, LabQuest2, LabQuest3, LabQuestMini and LabQuest Stream data collectors. Does not work with GoLink data collector!

100,04
product.gdx-vpg._hero.001-600x338.jpgPhotogate, wireless

Using Go Direct Photogate, students are able to easily and accurately measure velocity and acceleration to study the movement of an object in free fall, rolling objects, collisions, and pendulums, without needing to know anything about the geometry of the object.

Go Direct Photogate also includes a single laser gate for use with objects passing outside of the arms of the sensor. Using the laser gate requires a visible-light pen laser (not included).

Go Direct Photogate can be used in a variety of experiments:

  • Measuring acceleration of a cart on an incline using a cart picket fence
  • Measuring the angular motion of a wheel as it is turning
  • Investigating Newton’s second law using a half-Atwood machine to measure acceleration
  • Determining the time an object passes one or more gates

Rechargeable Battery—Ready When You Are

The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from our award-winning Vernier Graphical Analysis® app, as well as LabQuest® 3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting—no interruptions or inconvenience to you or your students.

Wireless or Wired—The Flexibility to Choose

Our Go Direct sensors connect directly to your mobile device, Chromebook, or computer using our Vernier Graphical Analysis® app—no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the best solution for your classroom or laboratory.

180,56
DM3605R.jpgPlastic ball d60mm for mechanics experiments

Ball D=60 mm, for dynamics and momentum conservation

9,00
421000.jpgPocket compass

Made of plastic, dimensions 37x43x12mm, weight 6g. Equipped with a hanging loop.

Made in Germany

3,90
polarisatsioon.jpgPolarization discs, 2 pcs, d210mm

The set includes a wooden stand and two freely rotating polaroids with a diameter of 21 cm. By turning the polaroids relative to each other, the light can be "faded".

57,50
dc15a312v.jpgPower supply 3-12V, 1,5A

Power supply with fixed output voltages 3; 4.5; 6; 7.5; 9 and 12V.

Load max 1.5A. Overload protection.

Lightweight, pulse-switched laboratory power supply to replace batteries.

Dimensions 180x80x110mm.

Weight 460g.

75,64
ACDCT3A12V.jpgPower supply AC/DC 3A, 0-12V, with analog display

Laboratory power supply. AC and DC voltage. Current 3A, voltage 0-12V continuously variable for DC voltage. Fixed AC voltage outputs 3V; 6V; 9V and 12V. Analog voltmeter on the front panel. Includes 4 pcs. 1m connection cables with 4mm connectors.

180,56
55223.jpgPower supply DC voltage 1.5...15V, 1.5A

In a ventilated sheet steel housing with on/off switch and power cable, colored 4 mm safety connection sockets for DC voltage, continuously adjustable output voltage, stabilized and smoothed, overheating and short-circuit protection, moving coil voltmeter. All outputs galvanically isolated from the mains.

Approved for student experiments in accordance with the current directive on safety in teaching (RiSU). CE mark.

176,90
22606.jpgResistor 10 ohm

Equipped with sockets for 4mm banana plugs.

3,66
1196056.jpgResistor 100 ohm on base

Resistance 100 Ω / 10 W ±1% on base with rubber feet and 4 mm safety banana sockets.

29,00
22606.jpgResistor 5 ohm
Equipped with sockets for 4mm banana plugs.
3,66
A variety kinds of resistance MS320.4_l.jpgResistors on base

Resistors 5, 10, 15, 200, 470 ohms and 1, 2, 10, 50, 100 kilo-ohms.

17,92
54535.jpgResistors, 10/50/100 Ohm, with sockets

Windings visible, on base with 4 mm connection sockets.

66,97
22185.jpgRheostat 10 Ohm

For current up to 2 A. With sockets for 4mm pin connectors.

17,08
22626.jpgScreen for experiments in optics, 12x13cm

Plastic screen with base. Dimensions 120 x 130 mm. Base height 23mm.

12,20
P33085K.jpgSet of 4 balls

For experiments on swimming, floating and sinking in water, also in mechanics;

Material: wood, glass, steel, styrofoam

Diameter of the balls: approx. 20 mm each

Mass of the balls: approx. 37 g

Packed in a plastic container with lid

Dimensions: 55 x 55 x 40 mm

Mass: approx. 48 g

8,00
drahteset.jpgSet of different wires

1 roll of wire, D=0.1 mm, L=30 m

1 roll of iron wire, D=0.2 mm, L=30 m

1 roll of copper wire, D=0.2 mm, L=30 m

1 roll of constantan wire, D=0.2 mm, L=30 m

1 roll of constantan wire, D=0.5 mm, L=15 m

1 box with lid

40,50
elektrood.jpgSet of electrodes, 6 pcs

Al, Zn, Pb, Cu, Brass, Fe. Dimensions 75x24x3mm, equipped with screw terminals.

30,67
schiebewiderstand20ohm2a.jpgSliding resistor 20 Ohm

Sliding resistor in an open design so that the sliding slider on the resistance wire winding is clearly visible,

with 3 sockets for safety and normal laboratory cables with 4 mm plugs;

Resistance: 20 Ohm, load capacity: 2 A (also higher for a short time), voltage: max. 42 V,

Dimensions: approx. 150 x 65 x 40 mm

54,00
P36001S.jpgSolar cell 1V, 200mA

For experiments on photovoltaics and solar technology, for converting radiation energy (sunlight) directly into electrical energy;

Polycrystalline solar cell with sealed surface, two connection cables with crocodile clips, copper tracks on the back for soldering, poles marked

Technical data:

Voltage: 1.0 V

Current: 200 mA

Power: 0.2 W

Length of cables: approx. 20 cm each

Dimensions: 75 x 45 x 3 mm

Weight: 18 g

10,50
paikesep.jpgSolar cell 2V, on stand

2V, 110mA, 4-mm sockets.

18,72
222131.jpgSpring set, different stiffness, 5 parts

2 N/m, 13 N/m, 22 N/m, 36 N/m and 50 N/m

20,20
IMG_3328.jpgStand h=50cm

The 5x8" stand consists of a 130x200mm base and a 50cm long rod.

28,06
stainlessball.jpgSteel ball 30mm
Mass 100g
5,35
avessa_cg_505_kronometre-250x273.jpgStopwatch, digital

Digital stopwatch with clock. Main numbers height 8mm.

12,34
22045.jpgStopwatch, mechanical, with one button

Classic mechanical stopwatch.

Large circle 30 seconds, small circle 15 minutes.

73,20
p33201a2.jpgStudent ammeter, protected

Analogue hand-held measuring device for current (ammeter), especially suitable for student experiments thanks to electronic overload protection.

Technical data:

Measuring ranges DC and AC: 10, 30, 100, 300 mA, 1, 3, 10 A

Selector switch: DC, AC, battery check, off

Moving coil measuring mechanism with mirror scale, arc length: approx. 90 mm

Overload protection with diodes and LED display

Accuracy: 2% (DC), 3% (AC)

Own consumption: 100 mW (+ fuse)

Usable frequency range for AC: 15 Hz ... 20 kHz

Maximum permissible input voltage: 30 Veff

Power supply: 4 x AA batteries

(Battery life: approx. 3 years)

Dimensions: approx. 200 x 140 x 100 mm

Weight: approx. 630 g

155,00
p32201v.jpgStudent voltmeter, protected

Analogue hand-held voltage measuring device, especially suitable for student experiments thanks to electronic overload protection.

Technical data:

Measuring ranges DC and AC: 100, 300 mV, 1, 3, 10, 30 V

Selector switch: DC, AC, battery check, off

Moving coil measuring device with mirror scale

Arc length: approx. 90 mm

Overload protection with diodes

Accuracy: 2% (DC), 3% (AC)

Internal resistance: 100 kOhm/V

Usable frequency range for AC: 15 Hz ... 20 kHz

Maximum permissible input voltage: 30 Veff

Power supply: 4 x AA batteries (battery life: approx. 3 years)

Dimensions: approx. 200 x 140 x 100 mm

Weight: approx. 600 g

111,00
DM6802S3.jpgTowed doubled test body for studying the coefficient of friction

For experiments on static, sliding and rolling friction,

by "unfolding" the block, the wood friction surface can be doubled;

Wooden block with four different surfaces: wood, rubber, leather and sandpaper, one end with a pull cord

Dimensions: 40x40x160 mm

Weight: approx. 200 g

63,44
DM6802R.jpgTowed test body for studying the coefficient of friction

For tests on static, sliding and rolling friction;

Painted wooden block with hook, a hook on the front for hanging a force gauge,

a central hole for stability tests

Dimensions: 160x80x40 mm, weight: approx. 350 g

37,82
u-shape-magnet.jpgU-magnet 65mm AlNiCo

Material AlNiCo. Strong U-magnet with dimensions 66x53x(20x6)mm

15,25
product.go-mot._physics._hs._features.001.590.332.jpgUSB motion sensor
Go!Motion is used to collect position, velocity and acceleration data of moving objects. Go!Motion’s USB port allows for direct connection to a computer’s USB port, which simplifies experiment set up. Students learn experientially as they graph the motion of a ball, a cart on a ramp, pendulum motion, or themselves. Go!Motion is easy to use, allowing students to focus on learning scientific concepts instead of setting up the lab. Go!Motion’s head pivots to match the needs of your lab. Flip the head halfway for monitoring the motion of a cart on a track, or flip 180° to record motion data from a tripod. Use the metal screw mount to attach the Go!Motion to a track, such as the Vernier Dynamics System, for studies of velocity and acceleration. Go!Motion features reduced noise and automatic temperature compensation to ensure motion readings are continuously accurate. The sensitivity switch lets you customize settings to your experiment. Measure motion data as close as 15 cm and as far away as 6 m!
241,56
22186.jpgVernier calliper, digital

Digital caliper 0..15 cm, 0.01mm

37,88
1172039.jpgVoltmeter, DC and AC, analog

DC voltage: 0.1 / 1 / 10 / 100 / 1000 V, accuracy 2% of full scale

AC voltage: 3 / 10 / 100 / 1000 V, accuracy 3% of full scale

Internal resistance DC: 2kΩ (0.1 V) to 20 MΩ (1000 V)

Internal resistance DC: 27kΩ (3 V) to 9 MΩ (1000 V)

Display: moving coil instrument with mirror scale

95,00
product_prices_with_vat
